pBMN HA-ATG13(W50D)
(Plasmid #188639)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 188639 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pBMN
  • Total vector size (bp) 6581
  • Vector type
    Mammalian Expression, Retroviral

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    NEB Stable
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    ATG13
  • Alt name
    KIAA0652
  • Alt name
    PARATARG8
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    1551
  • Mutation
    Changed tryptophan 50 to aspartic acid
  • Entrez Gene
    ATG13 (a.k.a. KIAA0652, PARATARG8)
  • Tag / Fusion Protein
    • HA (N terminal on insert)

Cloning Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pBMN HA-ATG13(W50D) was a gift from Michael Lazarou (Addgene plasmid # 188639 ; http://n2t.net/addgene:188639 ; RRID:Addgene_188639)

  • For your References section:

    Structural basis for ATG9A recruitment to the ULK1 complex in mitophagy initiation. Ren X, Nguyen TN, Lam WK, Buffalo CZ, Lazarou M, Yokom AL, Hurley JH. Sci Adv. 2023 Feb 15;9(7):eadg2997. doi: 10.1126/sciadv.adg2997. Epub 2023 Feb 15. 10.1126/sciadv.adg2997 PubMed 36791199
