pHR Grb2-TagBFP
(Plasmid #188631)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 188631 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pHR
  • Total vector size (bp) 10347
  • Vector type
    Mammalian Expression, Lentiviral

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    NEB Stable
  • Copy number
    Unknown

Gene/Insert

  • Gene/Insert name
    GRB2
  • Species
    H. sapiens (human), Synthetic
  • Insert Size (bp)
    1404
  • Entrez Gene
    GRB2 (a.k.a. ASH, EGFRBP-GRB2, Grb3-3, MST084, MSTP084, NCKAP2)
  • Promoter SFFV
  • Tag / Fusion Protein
    • TagBFP (C terminal on insert)

Cloning Information

  • Cloning method Gibson Cloning
  • 5′ sequencing primer ccgacagactgagtcgcccggg
  • 3′ sequencing primer ccagaggttgattatcgataagc
    • (Common Sequencing Primers)

Resource Information

Terms and Licenses

Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

Please visit https://doi.org/10.1101/2022.08.13.503850 for bioRxiv preprint.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pHR Grb2-TagBFP was a gift from Jared Toettcher (Addgene plasmid # 188631 ; http://n2t.net/addgene:188631 ; RRID:Addgene_188631)

  • For your References section:

    pYtags enable spatiotemporal measurements of receptor tyrosine kinase signaling in living cells. Farahani PE, Yang X, Mesev EV, Fomby KA, Brumbaugh-Reed EH, Bashor CJ, Nelson CM, Toettcher JE. eLife. 2023 May 22;12:e82863. doi: 10.7554/eLife.82863. 10.7554/eLife.82863 PubMed 37212240
