pGB-06-07-Vps34
(Plasmid #187989)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 187989 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pGB-06-07
  • Backbone size w/o insert (bp) 2935
  • Total vector size (bp) 5599
  • Vector type
    Bacterial Expression, Insect Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Gentamicin, 10 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    Unknown

Gene/Insert

  • Gene/Insert name
    Vps34
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    2664
  • GenBank ID
    5289 NM_002647
  • Entrez Gene
    PIK3C3 (a.k.a. VPS34, Vps34, hVps34)

Cloning Information

  • Cloning method Gibson Cloning
  • 5′ sequencing primer cCcggtccgaaaccATGGGCGAAGCGGAGAAAT
  • 3′ sequencing primer TCCCCAGAACATCAGGTTAATGGCGTTATTTT
    • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pGB-06-07-Vps34 was a gift from Sascha Martens (Addgene plasmid # 187989 ; http://n2t.net/addgene:187989 ; RRID:Addgene_187989)
