GB4367
(Plasmid #187817)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 187817 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pDGB3_omega1
  • Vector type
    Plant Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Spectinomycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    Moth Pheromone pathway
  • Species
    Synthetic

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site Unknown (unknown if destroyed)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

Contains the Transcriptional Units for constitutive expression of kanamycin resistance, and for dCasEV2.1-regulated expression of HarFAR, SpATF1-2 and Atr delta11

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    GB4367 was a gift from Diego Orzaez (Addgene plasmid # 187817 ; http://n2t.net/addgene:187817 ; RRID:Addgene_187817)

  • For your References section:

    Tunable control of insect pheromone biosynthesis in Nicotiana benthamiana. Kallam K, Moreno-Gimenez E, Mateos-Fernandez R, Tansley C, Gianoglio S, Orzaez D, Patron N. Plant Biotechnol J. 2023 Apr 9. doi: 10.1111/pbi.14048. 10.1111/pbi.14048 PubMed 37032497
