Addgene

GB4068
(Plasmid #187810)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 187810 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pLX-B3_omega1
  • Vector type
    Plant Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Spectinomycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    Low Copy

Gene/Insert

  • Gene/Insert name
    copper-inducible dCasEV2.1
  • Species
    Synthetic

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site Unknown (unknown if destroyed)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

Contains the Transcriptional Units for constitutive expression of hygromycin resistance and CUP2:GAL4, and for copper-inducible expression of dCas9:EDLL and MS2:VPR (dCasEV2.1)

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    GB4068 was a gift from Diego Orzaez (Addgene plasmid # 187810 ; http://n2t.net/addgene:187810 ; RRID:Addgene_187810)

  • For your References section:

    Tunable control of insect pheromone biosynthesis in Nicotiana benthamiana. Kallam K, Moreno-Gimenez E, Mateos-Fernandez R, Tansley C, Gianoglio S, Orzaez D, Patron N. Plant Biotechnol J. 2023 Apr 9. doi: 10.1111/pbi.14048. 10.1111/pbi.14048 PubMed 37032497
