mCherry-Climp63(1–192)
(Plasmid #186955)

• Purpose: Expresses mCherry-Climp63 with partial luminal domain
• Depositing Lab: Ke Xu
• Publication: Wang et al Proc Natl Acad Sci U S A. 2022 May 3;119(18):e2117559119. doi: 10.1073/pnas.2117559119. Epub 2022 Apr 26.

Backbone

• Vector backbone: pcDNA3.1
• Backbone size w/o insert (bp): 5345
• Total vector size (bp): 6653
• Vector type: Mammalian Expression
• Selectable markers: Neomycin (select with G418)

Growth in Bacteria

• Bacterial Resistance(s): Ampicillin, 100 μg/mL
• Growth Temperature: 37°C
• Growth Strain(s): DH5alpha
• Copy number: High Copy

Gene/Insert

• Gene/Insert name: Ckap4
• Alt name: Climp63
• Species: M. musculus (mouse)
• Insert Size (bp): 579
• Mutation: Only remain partial luminal domain
• GenBank ID:
• Entrez Gene: Ckap4 (a.k.a. 5630400A09Rik, CLIMP-63, P63)
• Promoter: CMV Promoter
• Tag / Fusion Protein:
  • mCherry (N terminal on insert)

Cloning Information

• Cloning method: Gibson Cloning
• 5′ sequencing primer: cgcaaatgggcggtaggcgtg
• 3′ sequencing primer: tagaaggcacagtcgagg

Resource Information

• Supplemental Documents:
  • pcdna3-1-mcherry-climp631-192.gb
• A portion of this plasmid was derived from a plasmid made by: Plasmid #136293 from Addgene

Terms and Licenses

• Academic/Nonprofit Terms:
  • UBMTA
  • Takara Bio Limited Use Label License (formerly Clontech)
• Industry Terms:
  • Not Available to Industry
