PurposeNAD+ biosensor comprised of a circularly permuted Venus fluorescent protein (cpVenus), a bipartite NAD+-binding domain modeled from bacterial DNA ligase, and a localization tag to target the cytoplasm
-
Depositing Lab
-
Sequence Information
Ordering
This material is available to academics and nonprofits only.
| Item | Catalog # | Description | Quantity | Price (USD) | |
|---|---|---|---|---|---|
| Plasmid | 186787 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 | |
Backbone
-
Vector backbonepCMV-Flag-HA-CcdB-IRES-puro
-
Vector typeMammalian Expression, Lentiviral
-
Selectable markersPuromycin
Growth in Bacteria
-
Bacterial Resistance(s)Ampicillin, 100 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)NEB Stable
-
Copy numberHigh Copy
Gene/Insert
-
Gene/Insert namecytoplasmic NAD+ biosensor
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
How to cite this plasmid
( Back to top)
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
cytoplasmic NAD+ biosensor was a gift from Michael Cohen (Addgene plasmid # 186787 ; http://n2t.net/addgene:186787 ; RRID:Addgene_186787) -
For your References section:
Biosensor reveals multiple sources for mitochondrial NAD(+). Cambronne XA, Stewart ML, Kim D, Jones-Brunette AM, Morgan RK, Farrens DL, Cohen MS, Goodman RH. Science. 2016 Jun 17;352(6292):1474-7. doi: 10.1126/science.aad5168. 10.1126/science.aad5168 PubMed 27313049
