puc19_N_tag
(Plasmid #186650)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 186650 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pUC19
  • Vector type
    Insect Expression
  • Selectable markers
    Puromycin

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    N-terminal 3xFlag-3xHA Tag
  • Species
    D. melanogaster (fly)
  • Tag / Fusion Protein
    • 3xFlag-3xHA (N terminal on insert)

Cloning Information

  • Cloning method Gibson Cloning

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

Contains the selection intron for Drosophila melanogaster and 3xFlag-3xHA epitope tag. Both are flanked by BbsI restrictions sites to enable cloning of homology arms using HIFI system. The selectable marker (puromycin) is located in the intron and is driven by its own minimal Act5C promoter.

Please visit https://www.biorxiv.org/content/10.1101/2020.12.18.423517v1 for bioRxiv preprint.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    puc19_N_tag was a gift from Astrid Haase (Addgene plasmid # 186650 ; http://n2t.net/addgene:186650 ; RRID:Addgene_186650)

  • For your References section:

    Functional editing of endogenous genes through rapid selection of cell pools (Rapid generation of endogenously tagged genes in Drosophila ovarian somatic sheath cells). Meng Q, Stoyko D, Andrews CM, Konstantinidou P, Genzor P, O T, Elchert AR, Benner L, Sobti S, Katz EY, Haase AD. Nucleic Acids Res. 2022 May 27. pii: 6594084. doi: 10.1093/nar/gkac448. 10.1093/nar/gkac448 PubMed 35639929
