pNbGFP-miRFP670nano3
(Plasmid
#184687)
-
PurposeNanobody to GFP labelled with near-infrared fluorescent protein miRFP670nano3
-
Depositing Lab
-
Sequence Information
-
Sequences (1) — Accept Affinity Reagent Sequence Policy
-
Ordering
This material is available to academics and nonprofits only.
| Item | Catalog # | Description | Quantity | Price (USD) | |
|---|---|---|---|---|---|
| Plasmid | 184687 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 | |
Backbone
-
Vector backbonepcDNA3.1
-
Backbone manufacturerInvitrogen
-
Vector typeMammalian Expression
Growth in Bacteria
-
Bacterial Resistance(s)Ampicillin, 100 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberHigh Copy
Gene/Insert
-
Gene/Insert nameNbGFP-miRFP670nano3
-
SpeciesSynthetic
- Promoter CMV
-
Tag
/ Fusion Protein
- miRFP670nano3 (C terminal on insert)
Cloning Information
- Cloning method Unknown
- 5′ sequencing primer CMV Forward
- 3′ sequencing primer BGH Reverse (Common Sequencing Primers)
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
How to cite this plasmid
( Back to top)
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pNbGFP-miRFP670nano3 was a gift from Vladislav Verkhusha (Addgene plasmid # 184687 ; http://n2t.net/addgene:184687 ; RRID:Addgene_184687) -
For your References section:
Single-domain near-infrared protein provides a scaffold for antigen-dependent fluorescent nanobodies. Oliinyk OS, Baloban M, Clark CL, Carey E, Pletnev S, Nimmerjahn A, Verkhusha VV. Nat Methods. 2022 May 23. pii: 10.1038/s41592-022-01467-6. doi: 10.1038/s41592-022-01467-6. 10.1038/s41592-022-01467-6 PubMed 35606446
