PRDM9(KRAB-SSXRD-PR/SET-ZF1-dC)-Cas9
(Plasmid #184464)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 184464 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pCAGGS
  • Backbone size w/o insert (bp) 4790
  • Total vector size (bp) 10907
  • Vector type
    Mammalian Expression, CRISPR
  • Selectable markers
    Puromycin

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    Unknown

Gene/Insert

  • Gene/Insert name
    PRDM9(KRAB-SSXRD-PR/SET-ZF1-dC)-Cas9
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    6120
  • Entrez Gene
    PRDM9 (a.k.a. KMT8B, MEISETZ, MSBP3, PFM6, ZNF899)
  • Promoter CMV
  • Tag / Fusion Protein
    • FLAG (C terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site EcoRI (not destroyed)
  • 3′ cloning site NheI (not destroyed)
  • 5′ sequencing primer CTCTAGAGCCTCTGCTAACC
  • 3′ sequencing primer GCCAGAAGTCAGATGCTCAAGG
    • (Common Sequencing Primers)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    PRDM9(KRAB-SSXRD-PR/SET-ZF1-dC)-Cas9 was a gift from Jennifer Doudna (Addgene plasmid # 184464 ; http://n2t.net/addgene:184464 ; RRID:Addgene_184464)

  • For your References section:

    Decorating chromatin for enhanced genome editing using CRISPR-Cas9. Chen E, Lin-Shiao E, Trinidad M, Saffari Doost M, Colognori D, Doudna JA. Proc Natl Acad Sci U S A. 2022 Dec 6;119(49):e2204259119. doi: 10.1073/pnas.2204259119. Epub 2022 Dec 2. 10.1073/pnas.2204259119 PubMed 36459645
