FAM19A1-V5
(Plasmid #184337)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 184337 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pEGFP-N3
  • Backbone manufacturer
    Clontech
  • Backbone size w/o insert (bp) 3975
  • Total vector size (bp) 4401
  • Modifications to backbone
    EGFP was replaced by V5-tag
  • Vector type
    Mammalian Expression
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    FAM19A1
  • Alt name
    TAFA1
  • Species
    M. musculus (mouse)
  • Insert Size (bp)
    399
  • Entrez Gene
    Tafa1 (a.k.a. C630007B19Rik, FAM19A1 TAFA-1, Fam19a1, Tafa-1)
  • Promoter CMV
  • Tag / Fusion Protein
    • V5-tag (C terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site NheI (not destroyed)
  • 3′ cloning site SalI (not destroyed)
  • 5′ sequencing primer CMV-for
  • 3′ sequencing primer EGFP-C-Rev
    • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    FAM19A1-V5 was a gift from Peter Scheiffele (Addgene plasmid # 184337 ; http://n2t.net/addgene:184337 ; RRID:Addgene_184337)

  • For your References section:

    Targeted proteoform mapping uncovers specific Neurexin-3 variants required for dendritic inhibition. Hauser D, Behr K, Konno K, Schreiner D, Schmidt A, Watanabe M, Bischofberger J, Scheiffele P. Neuron. 2022 May 8. pii: S0896-6273(22)00362-2. doi: 10.1016/j.neuron.2022.04.017. 10.1016/j.neuron.2022.04.017 PubMed 35550065
