pcDNA3-Dronpa-Kras
(Plasmid #182329)

• Purpose: Plasma membrane-targeted Dronpa. Fluctuating green-fluorescent label for live-cell super-resolution imaging.
• Depositing Lab: Jin Zhang
• Publication: Lin et al J Am Chem Soc. 2021 Sep 22;143(37):14951-14955. doi: 10.1021/jacs.1c05530. Epub 2021 Sep 13.

Backbone

• Vector backbone: pcDNA3
• Backbone size w/o insert (bp): 5517
• Total vector size (bp): 6234
• Vector type: Mammalian Expression
• Selectable markers: Neomycin (select with G418)

Growth in Bacteria

• Bacterial Resistance(s): Ampicillin, 100 μg/mL
• Growth Temperature: 37°C
• Growth Strain(s): DH5alpha
• Copy number: High Copy

Gene/Insert

• Gene/Insert name: Dronpa-Kras
• Insert Size (bp): 717
• Promoter: CMV
• Tags / Fusion Proteins:
  • 6xHIS - T7 tag (gene 10 leader) - Xpress (TM) tag (N terminal on backbone)
  • C-terminal targeting sequence from Kras (C terminal on insert)

Cloning Information

• Cloning method: Restriction Enzyme
• 5′ cloning site: BamHI (not destroyed)
• 3′ cloning site: EcoRI (not destroyed)
• 5′ sequencing primer: CMV forward
• 3′ sequencing primer: BGH reverse

Resource Information

• Supplemental Documents:
  • pcDNA3-Dronpa-Kras.gbk

Terms and Licenses

• Academic/Nonprofit Terms:
  • UBMTA
• Industry Terms:
  • Not Available to Industry
