pET28b-miniR-DBCO
(Plasmid
#181984)
-
PurposeUsed to label proteins with the MiniE genetically encoded tag
-
Depositing Lab
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 181984 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonepET28b
-
Backbone manufacturerNovagen
- Backbone size w/o insert (bp) 5368
-
Vector typeBacterial Expression
Growth in Bacteria
-
Bacterial Resistance(s)Kanamycin, 50 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)BL21-DE3*
-
Copy numberHigh Copy
Gene/Insert
-
Gene/Insert nameMiniR-DBCO
-
Alt nameMiniR
-
SpeciesSynthetic
-
Tag
/ Fusion Protein
- DBCO-Tag, His-Tag (C terminal on insert)
Cloning Information
- Cloning method Restriction Enzyme
- 5′ cloning site Unknown (unknown if destroyed)
- 3′ cloning site Unknown (unknown if destroyed)
- 5′ sequencing primer T7-F
- 3′ sequencing primer T7 REV (Common Sequencing Primers)
Resource Information
-
Supplemental Documents
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pET28b-miniR-DBCO was a gift from Kimberly Beatty (Addgene plasmid # 181984 ; http://n2t.net/addgene:181984 ; RRID:Addgene_181984) -
For your References section:
MiniVIPER Is a Peptide Tag for Imaging and Translocating Proteins in Cells. Doh JK, Tobin SJ, Beatty KE. Biochemistry. 2020 Aug 25;59(33):3051-3059. doi: 10.1021/acs.biochem.0c00526. Epub 2020 Aug 17. 10.1021/acs.biochem.0c00526 PubMed 32786411
