pcDNA3-AKAP79-AKAR4
(Plasmid #181957)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 181957 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pcDNA3
  • Backbone manufacturer
    Invitrogen
  • Backbone size w/o insert (bp) 5409
  • Total vector size (bp) 8739
  • Vector type
    Mammalian Expression
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    AKAP79-AKAR4
  • Alt name
    AKAP79-Cerulean-FHA1-PKAsub-cpVenus(E172)
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    3330
  • Entrez Gene
    AKAP5 (a.k.a. AKAP75, AKAP79, H21)
  • Promoter CMV
  • Tags / Fusion Proteins
    • HIS tag (N terminal on insert)
    • AKAP79 (N terminal on insert)
    • Cerulean (N terminal on insert)
    • cpVenus(E172) (C terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site HindIII (not destroyed)
  • 3′ cloning site EcoRI (not destroyed)
  • 5′ sequencing primer CMV forward
  • 3′ sequencing primer BGH reverse
    • (Common Sequencing Primers)

Resource Information

  • Supplemental Documents
  • A portion of this plasmid was derived from a plasmid made by
    AKAP79 cDNA was provided by John D. Scott (University of Washington).

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pcDNA3-AKAP79-AKAR4 was a gift from Jin Zhang (Addgene plasmid # 181957 ; http://n2t.net/addgene:181957 ; RRID:Addgene_181957)

  • For your References section:

    Spatially compartmentalized phase regulation of a Ca(2+)-cAMP-PKA oscillatory circuit. Tenner B, Getz M, Ross B, Ohadi D, Bohrer CH, Greenwald E, Mehta S, Xiao J, Rangamani P, Zhang J. Elife. 2020 Nov 17;9. pii: 55013. doi: 10.7554/eLife.55013. 10.7554/eLife.55013 PubMed 33201801
