pPHR-mCherry-nE-mHP1alpha-delCTE
(Plasmid #181891)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 181891 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pmCherry-N1
  • Backbone manufacturer
    Clontech
  • Backbone size w/o insert (bp) 3958
  • Vector type
    Mammalian Expression
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    PHR-mCherry-nE-mHP1alpha-delCTE
  • Alt name
    PHR domain of CRY2
  • Alt name
    CBX 5
  • Species
    M. musculus (mouse), A. thaliana (mustard weed)
  • Mutation
    S11E, S12E, S13E, S14E, 14 aa C-terminal deletion
  • Entrez Gene
    Cbx5 (a.k.a. 2610029O15Rik, HP1, Hp1a, Hp1alpha)
  • Promoter CMV
  • Tag / Fusion Protein
    • PHR-mCherry (N terminal on insert)

Cloning Information

  • Cloning method Unknown

Terms and Licenses

Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

For additional reference on HP1alpha, please see Larson et al. 2017 Nature, PMID 28636604, https://doi.org/10.1038/nature22822

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pPHR-mCherry-nE-mHP1alpha-delCTE was a gift from Karsten Rippe (Addgene plasmid # 181891 ; http://n2t.net/addgene:181891 ; RRID:Addgene_181891)

  • For your References section:

    Mouse Heterochromatin Adopts Digital Compaction States without Showing Hallmarks of HP1-Driven Liquid-Liquid Phase Separation. Erdel F, Rademacher A, Vlijm R, Tunnermann J, Frank L, Weinmann R, Schweigert E, Yserentant K, Hummert J, Bauer C, Schumacher S, Al Alwash A, Normand C, Herten DP, Engelhardt J, Rippe K. Mol Cell. 2020 Apr 16;78(2):236-249.e7. doi: 10.1016/j.molcel.2020.02.005. Epub 2020 Feb 25. 10.1016/j.molcel.2020.02.005 PubMed 32101700
