pPHR-mCherry-hHP1gamma
(Plasmid #181885)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 181885 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pmCherry-N1
  • Backbone manufacturer
    Clontech
  • Backbone size w/o insert (bp) 3958
  • Vector type
    Mammalian Expression
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    PHR-mCherry-hHP1gamma
  • Alt name
    PHR domain of CRY2
  • Alt name
    CBX 3
  • Species
    H. sapiens (human), A. thaliana (mustard weed)
  • Entrez Gene
    CBX3 (a.k.a. HECH, HP1-GAMMA, HP1Hs-gamma, HP1gamma)
  • Promoter CMV
  • Tag / Fusion Protein
    • PHR-mCherry (N terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site BspEI (not destroyed)
  • 3′ cloning site XbaI (not destroyed)

Terms and Licenses

Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

CDS for human HP1-gamma inserted into pPHR-mCherry via BspEI/XbaI

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pPHR-mCherry-hHP1gamma was a gift from Karsten Rippe (Addgene plasmid # 181885 ; http://n2t.net/addgene:181885 ; RRID:Addgene_181885)

  • For your References section:

    Mouse Heterochromatin Adopts Digital Compaction States without Showing Hallmarks of HP1-Driven Liquid-Liquid Phase Separation. Erdel F, Rademacher A, Vlijm R, Tunnermann J, Frank L, Weinmann R, Schweigert E, Yserentant K, Hummert J, Bauer C, Schumacher S, Al Alwash A, Normand C, Herten DP, Engelhardt J, Rippe K. Mol Cell. 2020 Apr 16;78(2):236-249.e7. doi: 10.1016/j.molcel.2020.02.005. Epub 2020 Feb 25. 10.1016/j.molcel.2020.02.005 PubMed 32101700
