Addgene

pcDNA3.1(+)-Myr-DnaJB1-PKAcat-mCherry
(Plasmid #181853)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 181853 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pcDNA3
  • Backbone manufacturer
    Invitrogen
  • Backbone size w/o insert (bp) 5354
  • Total vector size (bp) 7322
  • Vector type
    Mammalian Expression
  • Selectable markers
    Bleomycin

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    Myr-DnaJB1-PKAcat-mCherry
  • Alt name
    PKAcat(1-9)-DnaJB1(1-70)-PKAcat(16-351)-mCherry
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    1968
  • Entrez Gene
    PRKACA (a.k.a. CAFD1, PKACA, PPNAD4)
  • Entrez Gene
    DNAJB1 (a.k.a. HSPF1, Hdj1, Hsp40, RSPH16B, Sis1)
  • Promoter CMV
  • Tag / Fusion Protein
    • mCherry (C terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site HindIII (not destroyed)
  • 3′ cloning site XbaI (not destroyed)
  • 5′ sequencing primer CMV forward
  • 3′ sequencing primer BGH reverse
    • (Common Sequencing Primers)

Resource Information

Terms and Licenses

Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pcDNA3.1(+)-Myr-DnaJB1-PKAcat-mCherry was a gift from Jin Zhang (Addgene plasmid # 181853 ; http://n2t.net/addgene:181853 ; RRID:Addgene_181853)

  • For your References section:

    Phase Separation of a PKA Regulatory Subunit Controls cAMP Compartmentation and Oncogenic Signaling. Zhang JZ, Lu TW, Stolerman LM, Tenner B, Yang JR, Zhang JF, Falcke M, Rangamani P, Taylor SS, Mehta S, Zhang J. Cell. 2020 Sep 17;182(6):1531-1544.e15. doi: 10.1016/j.cell.2020.07.043. Epub 2020 Aug 25. 10.1016/j.cell.2020.07.043 PubMed 32846158
