Addgene

Lamp1-CFP
(Plasmid #1815)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 1815 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    pECFP-N1
  • Backbone manufacturer
    BD Biosciences / Clontech
  • Backbone size w/o insert (bp) 4700
  • Vector type
    Mammalian Expression
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    lysosome associated membrane protein 1
  • Alt name
    Lamp-1
  • Species
    R. norvegicus (rat)
  • Insert Size (bp)
    1200
  • Entrez Gene
    Lamp1 (a.k.a. LGP120)
  • Tag / Fusion Protein
    • CFP (C terminal on backbone)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site EcoRI (not destroyed)
  • 3′ cloning site BamHI (not destroyed)
  • 5′ sequencing primer EGFP-N
    • (Common Sequencing Primers)

Resource Information

  • Addgene Notes
  • A portion of this plasmid was derived from a plasmid made by
    Norma Andrews provided Lamp-1

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    Lamp1-CFP was a gift from Walther Mothes (Addgene plasmid # 1815)

  • For your References section:

    Visualization of retroviral replication in living cells reveals budding into multivesicular bodies. Sherer NM, Lehmann MJ, Jimenez-Soto LF, Ingmundson A, Horner SM, Cicchetti G, Allen PG, Pypaert M, Cunningham JM, Mothes W. Traffic 2003 Nov;4(11):785-801. 10.1034/j.1600-0854.2003.00135.x PubMed 14617360
