pBTK622
(Plasmid #180592)

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 180592 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    ColE1
  • Vector type
    Synthetic Biology

Growth in Bacteria

  • Bacterial Resistance(s)
    Chloramphenicol, 25 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert 1

  • Gene/Insert name
    tdk
  • Species
    Escherichia coli
  • Insert Size (bp)
    618

Gene/Insert 2

  • Gene/Insert name
    kanR
  • Alt name
    aphA1
  • Species
    Various Bacteria
  • Insert Size (bp)
    816

Resource Information

  • Supplemental Documents
  • A portion of this plasmid was derived from a plasmid made by
    tdk-KanR cassette from Valerie de Crecy-Lagard at the University of Florida. This cassette is in general usage in many labs studying Acinetobacter baylyi ADP1.

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

The tdk-KanR was decribed in Metzgar, David, Jamie M Bacher, Valérie Pezo, John Reader, Volker Döring, Paul Schimmel, Philippe Marlière, and Valérie de Crécy-Lagard. (2004) Acinetobacter Sp. ADP1: An Ideal Model Organism for Genetic Analysis and Genome Engineering. Nucleic Acids Research 32 (19): 5780–5790. https://doi.org/10.1093/nar/gkh881.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pBTK622 was a gift from Jeffrey Barrick (Addgene plasmid # 180592 ; http://n2t.net/addgene:180592 ; RRID:Addgene_180592)
  • For your References section:

    Rapid and assured genetic engineering methods applied to Acinetobacter baylyi ADP1 genome streamlining. Suarez GA, Dugan KR, Renda BA, Leonard SP, Gangavarapu LS, Barrick JE. Nucleic Acids Res. 2020 May 7;48(8):4585-4600. doi: 10.1093/nar/gkaa204. 10.1093/nar/gkaa204 PubMed 32232367
