pEF274 SVAfw
(Plasmid #178192)

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 178192 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    pJazz
  • Backbone manufacturer
    Lucigen.com
  • Backbone size w/o insert (bp) 12000
  • Total vector size (bp) 15400
  • Vector type
    Linear BAC vector

Growth in Bacteria

  • Bacterial Resistance(s)
    Chloramphenicol, 25 μg/mL
  • Growth Temperature
    30°C
  • Growth Strain(s)
    NEB Stable
  • Growth instructions
    Slower growing conditions (liquid culture: 30°C, 24 h, 150 rpm; plates: 30°C, 36 h; 12.5 μg/ml chloramphenicol) are necessary for proper maintenance of repeat sequences.
  • Copy number
    Low Copy

Gene/Insert

  • Gene/Insert name
    SVA that inserts into the X-linked human TAF1 gene to cause X-linked dystonia Parkinsonism
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    3400

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site Dra 1 (unknown if destroyed)
  • 3′ cloning site Dra 1 (unknown if destroyed)
  • 5′ sequencing primer AAATGGTCAGTTAATCAGTTCT- in pJAZZ backbone
  • 3′ sequencing primer CAGTCCAGTTACGCTGGAGTC- in pJAZZ backbone
  • (Common Sequencing Primers)

Resource Information

  • Supplemental Documents
  • A portion of this plasmid was derived from a plasmid made by
    Cris Bragg, Mass General Hospital, Boston ([email protected]) provided the insert in a topo vector, we cloned it into a pJazz linear BAC vector.

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

This clone contains the SVA (SINE-VNTR-ALU repeat) that when inserted into intron 32 of the human TAF1 gene causes X-linked dystonia Parkinsonism (XDP). Importantly, the SVA is cloned into a linear BAC vector which allows the 53 consecutive hexanucleotide repeats of this SVA to stay stable when propagated at 30oC i.e. no repeat expansions or reductions. SVA originally came from the lab of Dr. Cris Bragg, MGH, Boston, USA.

Please Note: Addgene NGS found some T nucleotides present within the poly-A tail. This is not known to affect the plasmid's function.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pEF274 SVAfw was a gift from Elizabeth Fisher (Addgene plasmid # 178192 ; http://n2t.net/addgene:178192 ; RRID:Addgene_178192)
