pBSKΔBS-SD_MCS_SA(NBSI)-24xMS2-sirius-96xopto-TetO-Int-3xFLAG-NeoR-GS4
(Plasmid
#177265)
-
PurposeSTREAMING-tag cassette
-
Depositing Lab
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 177265 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonepBluescript II Phagemid Vectors
-
Backbone manufacturerAgilent
- Backbone size w/o insert (bp) 2961
-
Modifications to backboneThe BbsI and BsaI sites have been removed from the original plasmid.
-
Vector typeUnspecified
Growth in Bacteria
-
Bacterial Resistance(s)Ampicillin, 100 μg/mL
-
Growth Temperature30°C
-
Growth Strain(s)NEB Stable
-
Copy numberHigh Copy
Gene/Insert
-
Gene/Insert nameSTREAMING-tag cassette
-
SpeciesSynthetic
-
Insert Size (bp)5593
Cloning Information
- Cloning method Restriction Enzyme
- 5′ cloning site BsaI (not destroyed)
- 3′ cloning site BsaI (not destroyed)
- 5′ sequencing primer M13 fwr primer
- 3′ sequencing primer M13 rev primer (Common Sequencing Primers)
Resource Information
-
Supplemental Documents
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pBSKΔBS-SD_MCS_SA(NBSI)-24xMS2-sirius-96xopto-TetO-Int-3xFLAG-NeoR-GS4 was a gift from Hiroshi Ochiai (Addgene plasmid # 177265 ; http://n2t.net/addgene:177265 ; RRID:Addgene_177265) -
For your References section:
STREAMING-tag system reveals spatiotemporal relationships between transcriptional regulatory factors and transcriptional activity. Ohishi H, Shimada S, Uchino S, Li J, Sato Y, Shintani M, Owada H, Ohkawa Y, Pertsinidis A, Yamamoto T, Kimura H, Ochiai H. Nat Commun. 2022 Dec 20;13(1):7672. doi: 10.1038/s41467-022-35286-2. 10.1038/s41467-022-35286-2 PubMed 36539402
