pUb dRxCas13d + RxCas13d guide RNA
(Plasmid #176304)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 176304 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pUb-3xFLAG-MCS
  • Total vector size (bp) 8019
  • Vector type
    Insect Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    Unknown

Gene/Insert

  • Gene/Insert name
    RxCas13d
  • Alt name
    RfxCas13d
  • Mutation
    R239A, H244A, R858A, H863A
  • Promoter Ubi-p63e
  • Tag / Fusion Protein
    • HA tag (C terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site SalI (not destroyed)
  • 3′ cloning site AgeI (not destroyed)
  • 5′ sequencing primer ATGACAATACAAACTAAGATTTAGTCAG
    • (Common Sequencing Primers)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pUb dRxCas13d + RxCas13d guide RNA was a gift from Jeremy Wilusz (Addgene plasmid # 176304 ; http://n2t.net/addgene:176304 ; RRID:Addgene_176304)

  • For your References section:

    CRISPR/Cas13 effectors have differing extents of off-target effects that limit their utility in eukaryotic cells. Ai Y, Liang D, Wilusz JE. Nucleic Acids Res. 2022 Mar 4. pii: 6542487. doi: 10.1093/nar/gkac159. 10.1093/nar/gkac159 PubMed 35244715
