pBH31(gfcD-10xHis)
(Plasmid #176200)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 176200 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pBH31
  • Backbone manufacturer
    from Dr Frank Collart
  • Vector type
    Bacterial Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    Unknown

Gene/Insert

  • Gene/Insert name
    gfcD
  • Alt name
    ymcA
  • Species
    E. coli E2348/69 O127:H6
  • Promoter T7
  • Tag / Fusion Protein
    • pelC leader-10xHis (N terminal on insert)

Cloning Information

  • Cloning method Ligation Independent Cloning
  • 5′ sequencing primer T7
  • 3′ sequencing primer T7 Terminator TATGCTAGTTATTGCTCAG
    • (Common Sequencing Primers)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

encodes (pelC signal sequence)-His10-GfcD(22-698)

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pBH31(gfcD-10xHis) was a gift from Mark Saper (Addgene plasmid # 176200 ; http://n2t.net/addgene:176200 ; RRID:Addgene_176200)

  • For your References section:

    Escherichia coli O127 group 4 capsule proteins assemble at the outer membrane. Larson MR, Biddle K, Gorman A, Boutom S, Rosenshine I, Saper MA. PLoS One. 2021 Nov 15;16(11):e0259900. doi: 10.1371/journal.pone.0259900. eCollection 2021. 10.1371/journal.pone.0259900 PubMed 34780538
