piggyBAC-5xTAPE-1-BlastR
(Plasmid #175808)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 175808 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    piggyBAC-BlastR
  • Backbone size w/o insert (bp) 6165
  • Total vector size (bp) 6279
  • Vector type
    Mammalian Expression
  • Selectable markers
    Blasticidin

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    30°C
  • Growth Strain(s)
    NEB Stable
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    5xTAPE-1 construct
  • Insert Size (bp)
    114
  • Promoter U6

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site BsmBI (destroyed during cloning)
  • 3′ cloning site BsmBI (destroyed during cloning)
  • 5′ sequencing primer GACTATCATATGCTTACCGT
    • (Common Sequencing Primers)

Resource Information

Terms and Licenses

Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    piggyBAC-5xTAPE-1-BlastR was a gift from Jay Shendure (Addgene plasmid # 175808 ; http://n2t.net/addgene:175808 ; RRID:Addgene_175808)

  • For your References section:

    A time-resolved, multi-symbol molecular recorder via sequential genome editing. Choi J, Chen W, Minkina A, Chardon FM, Suiter CC, Regalado SG, Domcke S, Hamazaki N, Lee C, Martin B, Daza RM, Shendure J. Nature. 2022 Jul 6. pii: 10.1038/s41586-022-04922-8. doi: 10.1038/s41586-022-04922-8. 10.1038/s41586-022-04922-8 PubMed 35794474
