pcDNA5/FRT/TO_H2B-HaloTag10-T2A-Tomm20-HaloTag9
(Plasmid
#175525)
-
PurposeCo-expression of HaloTag10 (nuclear) and 9 (mitochondrial surface) in mammalian cells
-
Depositing Lab
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 175525 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonepCDNA5/FR/TO
-
Vector typeMammalian Expression
-
Selectable markersHygromycin
Growth in Bacteria
-
Bacterial Resistance(s)Ampicillin, 100 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberHigh Copy
Gene/Insert
-
Gene/Insert nameH2B-HaloTag10 and Tomm20-HaloTag9
-
Alt nameH2B-HaloTag10
-
Alt nameTomm20-HaloTag9
-
SpeciesH. sapiens (human)
-
MutationHaloTag10 = HaloTag7-Q165W and HaloTag9 = HaloTag7-Q165H-P174R
Cloning Information
- Cloning method Gibson Cloning
Resource Information
-
Supplemental Documents
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
Depositor Comments
Please note there are an additional 35 amino acids at the end of the insert. Depositor confirms these do not affect plasmid function. This plasmid was used in the experiments discussed in their publication.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pcDNA5/FRT/TO_H2B-HaloTag10-T2A-Tomm20-HaloTag9 was a gift from Kai Johnsson (Addgene plasmid # 175525 ; http://n2t.net/addgene:175525 ; RRID:Addgene_175525) -
For your References section:
Engineered HaloTag variants for fluorescence lifetime multiplexing. Frei MS, Tarnawski M, Roberti MJ, Koch B, Hiblot J, Johnsson K. Nat Methods. 2021 Dec 16. pii: 10.1038/s41592-021-01341-x. doi: 10.1038/s41592-021-01341-x. 10.1038/s41592-021-01341-x PubMed 34916672
