pJKW1813
(Plasmid
#174003)
-
PurposeExpresses PpCYP90G4 and AtATR1 for reconstitution of diosgenin biosynthesis in yeast
-
Depositing Lab
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 174003 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backboneMoClo-YTK
-
Vector typeYeast Expression
-
Selectable markersLEU2
Growth in Bacteria
-
Bacterial Resistance(s)Kanamycin, 50 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberUnknown
Gene/Insert 1
-
Gene/Insert namePpCYP90G4
-
SpeciesParis polyphylla
-
Insert Size (bp)1458
-
GenBank IDTRINITY_DN46772_c3_g1_i1
Gene/Insert 2
-
Gene/Insert nameATR1
-
Alt nameCYP reductase
-
SpeciesA. thaliana (mustard weed)
-
Entrez GeneATR1 (a.k.a. AT4G24520, AR1, ARABIDOPSIS CYTOCHROME REDUCTASE, F22K18.280, F22K18_280, P450 reductase 1)
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pJKW1813 was a gift from Jing-Ke Weng (Addgene plasmid # 174003 ; http://n2t.net/addgene:174003 ; RRID:Addgene_174003) -
For your References section:
Repeated evolution of cytochrome P450-mediated spiroketal steroid biosynthesis in plants. Christ B, Xu C, Xu M, Li FS, Wada N, Mitchell AJ, Han XL, Wen ML, Fujita M, Weng JK. Nat Commun. 2019 Jul 19;10(1):3206. doi: 10.1038/s41467-019-11286-7. 10.1038/s41467-019-11286-7 PubMed 31324795
