pGL3-noSV40-EC1.45-human_min1-opossum_min2
(Plasmid #173966)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 173966 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pGL3-Promoter, GenBank: U47298.2
  • Backbone manufacturer
    Promega
  • Backbone size w/o insert (bp) 5016
  • Vector type
    Luciferase

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    Human minimal enhancer region 1 (min1) and opossum minimal enhancer region 2 (min2) from SOX9 enhancer cluster EC1.45
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    491
  • Mutation
    See Depositor Comments Below
  • Promoter SV40 promoter

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site unknown (unknown if destroyed)
  • 5′ sequencing primer CGCTCTCCATCAAAACAAAACG
  • 3′ sequencing primer GAGTTAGGGGCGGGATGG
    • (Common Sequencing Primers)

Terms and Licenses

Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

Please note: The plasmid contains a T to C nucleotide mutation in the Human minimal enhancer region 1 (min1) and opossum minimal enhancer region 2 (min2) from SOX9 enhancer cluster EC1.45 compared to the depositor's provided sequence.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pGL3-noSV40-EC1.45-human_min1-opossum_min2 was a gift from Joanna Wysocka (Addgene plasmid # 173966 ; http://n2t.net/addgene:173966 ; RRID:Addgene_173966)

  • For your References section:

    Loss of Extreme Long-Range Enhancers in Human Neural Crest Drives a Craniofacial Disorder. Long HK, Osterwalder M, Welsh IC, Hansen K, Davies JOJ, Liu YE, Koska M, Adams AT, Aho R, Arora N, Ikeda K, Williams RM, Sauka-Spengler T, Porteus MH, Mohun T, Dickel DE, Swigut T, Hughes JR, Higgs DR, Visel A, Selleri L, Wysocka J. Cell Stem Cell. 2020 Nov 5;27(5):765-783.e14. doi: 10.1016/j.stem.2020.09.001. Epub 2020 Sep 28. 10.1016/j.stem.2020.09.001 PubMed 32991838
