pX459-dTgfa
(Plasmid #173698)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 173698 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pX459
  • Backbone manufacturer
    https://www.addgene.org/48139/
  • Backbone size w/o insert (bp) 3200
  • Total vector size (bp) 9200
  • Vector type
    Mammalian Expression, CRISPR
  • Selectable markers
    Puromycin

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    Unknown

Gene/Insert

  • Gene/Insert name
    A gRNA targeting the dog Tgfa gene and the cDNA of CRISPR-Cas9
  • Insert Size (bp)
    5000

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site BsmBI (unknown if destroyed)
  • 3′ cloning site BsmBI (unknown if destroyed)
  • 5′ sequencing primer TTTATGGCGAGGCGGCGG
    • (Common Sequencing Primers)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pX459-dTgfa was a gift from Michiyuki Matsuda (Addgene plasmid # 173698 ; http://n2t.net/addgene:173698 ; RRID:Addgene_173698)

  • For your References section:

    Redundant roles of EGFR ligands in the ERK activation waves during collective cell migration. Lin S, Hirayama D, Maryu G, Matsuda K, Hino N, Deguchi E, Aoki K, Iwamoto R, Terai K, Matsuda M. Life Sci Alliance. 2021 Oct 19;5(1). pii: 5/1/e202101206. doi: 10.26508/lsa.202101206. Print 2022 Jan. 10.26508/lsa.202101206 PubMed 34667080
