pET22b-6h-GST-TEVp
(Plasmid #172887)

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 172887 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    pET22b
  • Backbone manufacturer
    Novagen
  • Backbone size w/o insert (bp) 5359
  • Total vector size (bp) 6779
  • Vector type
    Bacterial Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    TEV protease
  • Alt name
    Tevp
  • Alt name
    Tobacco etch virus protease
  • Species
    Synthetic
  • Insert Size (bp)
    708
  • Promoter T7 promoter
  • Tags / Fusion Proteins
    • GST solubility tag (N terminal on insert)
    • HHHHHH (N terminal on insert)

Cloning Information

  • Cloning method Gibson Cloning
  • 5′ sequencing primer TAATACGACTCACTATAGGG
  • 3′ sequencing primer GCTAGTTATTGCTCAGCGG
  • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pET22b-6h-GST-TEVp was a gift from Urartu Seker (Addgene plasmid # 172887 ; http://n2t.net/addgene:172887 ; RRID:Addgene_172887)
  • For your References section:

    A Self-Actuated Cellular Protein Delivery Machine. Ahan RE, Kirpat BM, Saltepe B, Seker UOS. ACS Synth Biol. 2019 Apr 19;8(4):686-696. doi: 10.1021/acssynbio.9b00062. Epub 2019 Mar 12. 10.1021/acssynbio.9b00062 PubMed 30811932
