mCherry-Sec61β
(Plasmid #172445)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 172445 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pmCherry-C1
  • Vector type
    Mammalian Expression
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    Protein transport protein Sec61 subunit beta
  • Species
    H. sapiens (human)
  • Promoter CMV
  • Tag / Fusion Protein
    • mCherry (N terminal on backbone)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site BglII (not destroyed)
  • 3′ cloning site EcoRI (not destroyed)
  • 5′ sequencing primer CMV-F
    • (Common Sequencing Primers)

Resource Information

  • A portion of this plasmid was derived from a plasmid made by
    Addgene plasmid 15108

Terms and Licenses

Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    mCherry-Sec61β was a gift from Stephen Royle (Addgene plasmid # 172445 ; http://n2t.net/addgene:172445 ; RRID:Addgene_172445)

  • For your References section:

    Endomembranes promote chromosome missegregation by ensheathing misaligned chromosomes. Ferrandiz N, Downie L, Starling GP, Royle SJ. J Cell Biol. 2022 Jun 6;221(6). pii: 213189. doi: 10.1083/jcb.202203021. Epub 2022 Apr 29. 10.1083/jcb.202203021 PubMed 35486148
