VHACg/pDONR221
(Plasmid
#172094)
-
PurposeGenomic fragment containing the upstream region and coding region of DET3/VHA-C cloned into pDONR221
-
Depositing Lab
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 172094 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 * |
* Log in to view industry pricing.
Backbone
-
Vector backbonepDONR221
-
Backbone manufacturerInvitrogen
- Backbone size w/o insert (bp) 4762
- Total vector size (bp) 7926
-
Modifications to backbonenone
-
Vector typeGateway Entry vector
Growth in Bacteria
-
Bacterial Resistance(s)Kanamycin, 50 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberHigh Copy
Gene/Insert
-
Gene/Insert nameVHA-C genomic region including 530bp upstream of the ATG, exons, introns, and no stop codon
-
Alt nameDET3
-
SpeciesA. thaliana (mustard weed)
-
Insert Size (bp)3225
-
GenBank IDNC_003075.7
-
Entrez GeneDET3 (a.k.a. AT1G12840, ARABIDOPSIS THALIANA VACUOLAR ATP SYNTHASE SUBUNIT C, ATVHA-C, DE-ETIOLATED 3, F13K23.9, F13K23_9, VACUOLAR ATP SYNTHASE SUBUNIT C)
- Promoter 530bp upstream of VHA-C ATG
Cloning Information
- Cloning method Gateway Cloning
- 5′ sequencing primer M13For
- 3′ sequencing primer M13R (Common Sequencing Primers)
Resource Information
-
Supplemental Documents
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
Trademarks:
- Zeocin® is an InvivoGen trademark.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
VHACg/pDONR221 was a gift from George Haughn (Addgene plasmid # 172094 ; http://n2t.net/addgene:172094 ; RRID:Addgene_172094) -
For your References section:
ECERIFERUM11/C-TERMINAL DOMAIN PHOSPHATASE-LIKE2 Affects Secretory Trafficking. Shi L, Dean GH, Zheng H, Meents MJ, Haslam TM, Haughn GW, Kunst L. Plant Physiol. 2019 Nov;181(3):901-915. doi: 10.1104/pp.19.00722. Epub 2019 Sep 4. 10.1104/pp.19.00722 PubMed 31484679
