PEA1-Nuclease-GFP
(Plasmid #171994)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 171994 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pCMV-PE2
  • Vector type
    Mammalian Expression
  • Selectable markers
    GFP

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    CbH-Cas9-RT-T2A-GFP, hU6-pegRNA (Bbs1 gate), hU6-sgRNA (Bbs1 gate)
  • Species
    Synthetic; Cas9 is from S. pyogenes; M-MLV RT is from the Moloney murine leukemia virus
  • Mutation
    GC to CA point mutation in SpCas9 to restore nuclease function
  • Promoter CMV for Cas9, U6 for gRNAs

Cloning Information

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    PEA1-Nuclease-GFP was a gift from Paul Thomas (Addgene plasmid # 171994 ; http://n2t.net/addgene:171994 ; RRID:Addgene_171994)

  • For your References section:

    Optimized nickase- and nuclease-based prime editing in human and mouse cells. Adikusuma F, Lushington C, Arudkumar J, Godahewa GI, Chey YCJ, Gierus L, Piltz S, Geiger A, Jain Y, Reti D, Wilson LOW, Bauer DC, Thomas PQ. Nucleic Acids Res. 2021 Sep 17. pii: 6371974. doi: 10.1093/nar/gkab792. 10.1093/nar/gkab792 PubMed 34534334
