pMCB619
(Plasmid #171011)

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 171011 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    pCRISPRia-v2
  • Backbone size w/o insert (bp) 9000
  • Vector type
    Mammalian Expression, Lentiviral, CRISPR
  • Selectable markers
    Puromycin ; BFP

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    NEB Stable
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    U6:sgRNA_Puro-T2A-BFP
  • gRNA/shRNA sequence
    Unspecified
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    50
  • Promoter mU6

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site Unknown (unknown if destroyed)

Resource Information

  • Supplemental Documents
  • A portion of this plasmid was derived from a plasmid made by
    Michael Bassik
  • Article Citing this Plasmid

Terms and Licenses

Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pMCB619 was a gift from Alice Ting (Addgene plasmid # 171011 ; http://n2t.net/addgene:171011 ; RRID:Addgene_171011)
  • For your References section:

    An engineered transcriptional reporter of protein localization identifies regulators of mitochondrial and ER membrane protein trafficking in high-throughput CRISPRi screens. Coukos RW, Yao D, Sanchez ML, Strand ET, Olive ME, Udeshi ND, Weissman JS, Carr SA, Bassik MC, Ting AY. Elife. 2021 Aug 20;10. pii: 69142. doi: 10.7554/eLife.69142. 10.7554/eLife.69142 PubMed 34414886
