pW188-lenti-spsgRNA-lacZ-pEF1s-NLS-mScarlet-I-P2A-BlastR
(Plasmid #170813)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 170813 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pW212 (Addgene #170810)
  • Vector type
    Mammalian Expression, Lentiviral

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    30°C
  • Growth Strain(s)
    NEB Stable
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    NLS-mScarlet-I-P2A-BlastR
  • gRNA/shRNA sequence
    gTGCGAATACGCCCACGCGAT
  • Species
    Synthetic; B. coriaceae
  • Insert Size (bp)
    1209
  • Mutation
    NA

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site Unknown (unknown if destroyed)
  • 3′ cloning site unknown (unknown if destroyed)
  • 5′ sequencing primer unknown
    • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

3rd generation lentiviral backbone. Please visit https://www.biorxiv.org/content/10.1101/2020.06.24.165795v2.full for bioRxiv preprint.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pW188-lenti-spsgRNA-lacZ-pEF1s-NLS-mScarlet-I-P2A-BlastR was a gift from Kenneth Yamada (Addgene plasmid # 170813 ; http://n2t.net/addgene:170813 ; RRID:Addgene_170813)

  • For your References section:

    Budding epithelial morphogenesis driven by cell-matrix versus cell-cell adhesion. Wang S, Matsumoto K, Lish SR, Cartagena-Rivera AX, Yamada KM. Cell. 2021 Jul 8;184(14):3702-3716.e30. doi: 10.1016/j.cell.2021.05.015. Epub 2021 Jun 15. 10.1016/j.cell.2021.05.015 PubMed 34133940
