pE5773
(Plasmid #170780)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 170780 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pET plus custom insert
  • Vector type
    Bacterial Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    Low Copy

Gene/Insert

  • Gene/Insert name
    GentR
  • Alt name
    gentamicin resistance
  • Insert Size (bp)
    860
  • Promoter T7
  • Tag / Fusion Protein
    • polyhisTEVSBPTEV (N terminal on backbone)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site BamH1 (not destroyed)
  • 3′ cloning site Xba1/HindIII (not destroyed)
  • 5′ sequencing primer CGTGCTCGTCTGGAACACCACCCGCAGG
    • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pE5773 was a gift from Anthony Schryvers (Addgene plasmid # 170780 ; http://n2t.net/addgene:170780 ; RRID:Addgene_170780)

  • For your References section:

    Design and Production of Hybrid Antigens for Targeting Integral Outer Membrane Proteins in Gram-Negative Bacteria. Chaudhuri S, Ewasechko NF, Samaniego-Barron L, Fegan JE, Schryvers AB. Methods Mol Biol. 2022;2414:115-140. doi: 10.1007/978-1-0716-1900-1_8. 10.1007/978-1-0716-1900-1_8 PubMed 34784035
