Epac-S-H170
(Plasmid #170352)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 170352 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pAdeno
  • Backbone size w/o insert (bp) 36000
  • Vector type
    Mammalian Expression, Adenoviral

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    NEB Stable
  • Copy number
    Unknown

Gene/Insert

  • Gene/Insert name
    mTurq2Del_EPACdDEPCD_cp173Ven(ST)_Ven(ST)
  • Species
    H. sapiens (human)
  • Mutation
    Deletion of DEP domain, Catalytically dead T781A & F782A, increased affinity for cAMP Q270E
  • Entrez Gene
    RAPGEF3 (a.k.a. CAMP-GEFI, EPAC, EPAC1, HSU79275, bcm910)
  • Promoter CMV

Cloning Information

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    Epac-S-H170 was a gift from Kees Jalink (Addgene plasmid # 170352 ; http://n2t.net/addgene:170352 ; RRID:Addgene_170352)

  • For your References section:

    Fourth-generation epac-based FRET sensors for cAMP feature exceptional brightness, photostability and dynamic range: characterization of dedicated sensors for FLIM, for ratiometry and with high affinity. Klarenbeek J, Goedhart J, van Batenburg A, Groenewald D, Jalink K. PLoS One. 2015 Apr 14;10(4):e0122513. doi: 10.1371/journal.pone.0122513. eCollection 2015. 10.1371/journal.pone.0122513 PubMed 25875503
