pPBbsr2-Necl-5-ScNeo
(Plasmid
#170283)
-
PurposeTo monitor the status of Necl-5, the plasmid encodes a recombinant Necl-5 fused extracellularly to the mScarlet fluorescent protein and intracellularly to the mNeonGreen fluorescent protein
-
Depositing Lab
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 170283 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonepPB
- Backbone size w/o insert (bp) 6800
- Total vector size (bp) 11368
-
Vector typeMammalian Expression
-
Selectable markersBlasticidin
Growth in Bacteria
-
Bacterial Resistance(s)Ampicillin, 100 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberUnknown
Gene/Insert
-
Gene/Insert namea recombinant mouse Necl-5 fused to the mScarlet and to the mNeonGreen fluorescent protein
-
Alt nameNecl-5-ScNeo
-
SpeciesM. musculus (mouse), Synthetic
-
Insert Size (bp)2300
-
Entrez GenePvr (a.k.a. 3830421F03Rik, CD155, D7Ertd458e, HVED, PVS, Taa1, Tage4, mE4, necl-5)
-
Tag
/ Fusion Protein
- mScarlet and mNeonGreen
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pPBbsr2-Necl-5-ScNeo was a gift from Michiyuki Matsuda (Addgene plasmid # 170283 ; http://n2t.net/addgene:170283 ; RRID:Addgene_170283) -
For your References section:
Functional visualization of NK Cell-mediated killing of metastatic single tumor cells. Ichise H, Tsukamoto S, Hirashima T, Konishi Y, Oki C, Tsukiji S, Iwano S, Miyawaki A, Sumiyama K, Terai K, Matsuda M. Elife. 2022 Feb 3;11. pii: 76269. doi: 10.7554/eLife.76269. 10.7554/eLife.76269 PubMed 35113018
