pBAD/His-D-iLight
(Plasmid #170270)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 170270 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    Modified pBAD/His-B
  • Backbone manufacturer
    Life Technologies-Invitrogen (partially modified)
  • Backbone size w/o insert (bp) 3999
  • Vector type
    Bacterial Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    Low Copy

Gene/Insert

  • Gene/Insert name
    iLight
  • Species
    Idiomarina sp. A28L
  • Insert Size (bp)
    1608
  • Mutation
    See Comments
  • Promoter araBAD
  • Tag / Fusion Protein
    • 6xHis tag (N terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site BglII (not destroyed)
  • 3′ cloning site EcoRI (not destroyed)
  • 5′ sequencing primer pBAD Forward
  • 3′ sequencing primer pBAD Reverse
    • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

To design iLight for expression in bacteria, a full-length bacterial phytochrome IsPadC from Idiomarina sp. A28L was used as an original template. First, diguanylyl cyclase effector in IsPadC was removed, then following mutations were introduced: I68F, H80Q, A86T, R90S S242C, E274K, R295H I360V, and L464V.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pBAD/His-D-iLight was a gift from Vladislav Verkhusha (Addgene plasmid # 170270 ; http://n2t.net/addgene:170270 ; RRID:Addgene_170270)

  • For your References section:

    Single-component near-infrared optogenetic systems for gene transcription regulation. Kaberniuk AA, Baloban M, Monakhov MV, Shcherbakova DM, Verkhusha VV. Nat Commun. 2021 Jun 23;12(1):3859. doi: 10.1038/s41467-021-24212-7. 10.1038/s41467-021-24212-7 PubMed 34162879
