pCW57.1 ISCU D71A
(Plasmid #169880)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 169880 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pCW57.1
  • Backbone size w/o insert (bp) 9354
  • Total vector size (bp) 9859
  • Modifications to backbone
    Polylinker altered from original plasmid
  • Vector type
    Mammalian Expression, Lentiviral
  • Selectable markers
    Puromycin

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    NEB Stable
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    ISCU
  • Alt name
    Iron-Sulfur Cluster Assembly Enzyme
  • Species
    H. sapiens (human), Synthetic
  • Insert Size (bp)
    504
  • Mutation
    Codon Optimized, D71A iron-sulfur cluster trapping mutation, dominant negative
  • Entrez Gene
    ISCU (a.k.a. 2310020H20Rik, HML, ISU2, NIFU, NIFUN, hnifU)
  • Promoter TRE

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site EcoRI (not destroyed)
  • 3′ cloning site NotI (not destroyed)
  • 5′ sequencing primer LNCX
    • (Common Sequencing Primers)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pCW57.1 ISCU D71A was a gift from Richard Possemato (Addgene plasmid # 169880 ; http://n2t.net/addgene:169880 ; RRID:Addgene_169880)

  • For your References section:

    Iron-sulfur cluster deficiency can be sensed by IRP2 and regulates iron homeostasis and sensitivity to ferroptosis independent of IRP1 and FBXL5. Terzi EM, Sviderskiy VO, Alvarez SW, Whiten GC, Possemato R. Sci Adv. 2021 May 26;7(22). pii: 7/22/eabg4302. doi: 10.1126/sciadv.abg4302. Print 2021 May. 10.1126/sciadv.abg4302 PubMed 34039609
