pDN34-BiNLS-hYAP1-1delta
(Plasmid #169471)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 169471 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pDN34
  • Backbone manufacturer
    Barbara Di Ventura
  • Total vector size (bp) 8212
  • Vector type
    Mammalian Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    Unknown

Gene/Insert

  • Gene/Insert name
    YAP1-1delta
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    2706
  • Entrez Gene
    YAP1 (a.k.a. COB1, YAP, YAP-1, YAP2, YAP65, YKI)
  • Promoter CMV
  • Tag / Fusion Protein
    • mCherry (N terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site XbaI (not destroyed)
  • 3′ cloning site XbaI (not destroyed)
  • 5′ sequencing primer ggtcgaTCTAGAATGTTAGCCTTGAAATTAGC
  • 3′ sequencing primer cgtcgcTCTAGACTATAACCATGTAAGAAAGC
    • (Common Sequencing Primers)

Terms and Licenses

Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

Vector backbone pDN34 is based on the LINuS method for optogenetic control of nuclear import.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pDN34-BiNLS-hYAP1-1delta was a gift from Timothy Saunders (Addgene plasmid # 169471 ; http://n2t.net/addgene:169471 ; RRID:Addgene_169471)

  • For your References section:

    Optogenetic control of YAP cellular localisation and function. Toh PJY, Lai JKH, Hermann A, Destaing O, Sheetz MP, Sudol M, Saunders TE. EMBO Rep. 2022 Sep 5;23(9):e54401. doi: 10.15252/embr.202154401. Epub 2022 Jul 25. 10.15252/embr.202154401 PubMed 35876586
