pET28a Gx-NL3
(Plasmid
#169108)
-
PurposeExpresses protein G fused to 3 copies of NanoLuc. The protein G domain contains an amber stop-codon at position 24 for incorporation of the unnatural amino acid para-benzoylphenylalanine.
-
Depositing Lab
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 169108 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonepET28a
- Backbone size w/o insert (bp) 5369
- Total vector size (bp) 7087
-
Vector typeBacterial Expression
Growth in Bacteria
-
Bacterial Resistance(s)Kanamycin, 50 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Growth instructionsBl21(DE3)
-
Copy numberHigh Copy
Gene/Insert
-
Gene/Insert nameprotein G - NanoLuc - NanoLuc - NanoLuc
-
SpeciesSynthetic
-
Insert Size (bp)1854
-
MutationAla 24 stop
- Promoter T7
-
Tags
/ Fusion Proteins
- strep-tag (N terminal on insert)
- his-tag (C terminal on insert)
Cloning Information
- Cloning method Restriction Enzyme
- 5′ cloning site NcoI (unknown if destroyed)
- 3′ cloning site XhoI (unknown if destroyed)
- 5′ sequencing primer T7 (Common Sequencing Primers)
Resource Information
-
Supplemental Documents
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pET28a Gx-NL3 was a gift from Maarten Merkx (Addgene plasmid # 169108 ; http://n2t.net/addgene:169108 ; RRID:Addgene_169108) -
For your References section:
Bioluminescent Antibodies through Photoconjugation of Protein G-Luciferase Fusion Proteins. Wouters SFA, Vugs WJP, Arts R, de Leeuw NM, Teeuwen RWH, Merkx M. Bioconjug Chem. 2020 Mar 18;31(3):656-662. doi: 10.1021/acs.bioconjchem.9b00804. Epub 2020 Jan 22. 10.1021/acs.bioconjchem.9b00804 PubMed 31909607
