pT2AL200R150G-EGFP-LC3B-RFP-LC3BΔG
(Plasmid #168998)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 168998 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pT2AL200R150G
  • Total vector size (bp) 4750
  • Vector type
    Unspecified

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    microtubule-associated protein 1 light chain 3 beta
  • Alt name
    Map1lc3b
  • Alt name
    LC3B
  • Species
    R. norvegicus (rat)
  • GenBank ID
    NM_022867.2
  • Entrez Gene
    Map1lc3b (a.k.a. LC3B, Map1lc3, Mpl3, zbs559)
  • Tags / Fusion Proteins
    • EGFP (N terminal on insert)
    • mRFP1 (C terminal on insert)

Terms and Licenses

Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pT2AL200R150G-EGFP-LC3B-RFP-LC3BΔG was a gift from Noboru Mizushima (Addgene plasmid # 168998 ; http://n2t.net/addgene:168998 ; RRID:Addgene_168998)

  • For your References section:

    An Autophagic Flux Probe that Releases an Internal Control. Kaizuka T, Morishita H, Hama Y, Tsukamoto S, Matsui T, Toyota Y, Kodama A, Ishihara T, Mizushima T, Mizushima N. Mol Cell. 2016 Nov 17;64(4):835-849. doi: 10.1016/j.molcel.2016.09.037. Epub 2016 Nov 3. 10.1016/j.molcel.2016.09.037 PubMed 27818143
