Vimentin-DiB-RM
(Plasmid #168783)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 168783 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    Vimentin-Citrine
  • Backbone size w/o insert (bp) 3948
  • Total vector size (bp) 5850
  • Vector type
    Mammalian Expression
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    Vimentin-DiB-RM
  • Species
    Synthetic
  • Insert Size (bp)
    1902
  • Promoter CMV

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site NheI (not destroyed)
  • 3′ cloning site NotI (not destroyed)
  • 5′ sequencing primer CGCAAATGGGCGGTAGGCGTG
  • 3′ sequencing primer CAAGTTAACAACAACAATTGCAT
    • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    Vimentin-DiB-RM was a gift from Jens Meiler (Addgene plasmid # 168783 ; http://n2t.net/addgene:168783 ; RRID:Addgene_168783)

  • For your References section:

    Computational redesign of a fluorogen activating protein with Rosetta. Bozhanova NG, Harp JM, Bender BJ, Gavrikov AS, Gorbachev DA, Baranov MS, Mercado CB, Zhang X, Lukyanov KA, Mishin AS, Meiler J. PLoS Comput Biol. 2021 Nov 8;17(11):e1009555. doi: 10.1371/journal.pcbi.1009555. eCollection 2021 Nov. 10.1371/journal.pcbi.1009555 PubMed 34748541
