pBLxVi5
(Plasmid
#167516)
-
PurposeBroad-Host range expression vector, pBBR origin, LuxR activator, PLuxB promoter, Violacein, Gentamicin Resistance Marker.
-
Depositing Lab
-
Sequence Information
Ordering
This material is available to academics and nonprofits only.
| Item | Catalog # | Description | Quantity | Price (USD) | |
|---|---|---|---|---|---|
| Plasmid | 167516 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 | |
Backbone
-
Vector backbonepBLxVi5
-
Vector typeBacterial Expression, Synthetic Biology
Growth in Bacteria
-
Bacterial Resistance(s)Gentamicin, 10 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberLow Copy
Gene/Insert
-
Gene/Insert nameLuxR-Violacein
-
SpeciesSynthetic
- Promoter PLuxB
Cloning Information
- Cloning method Ligation Independent Cloning
Resource Information
-
A portion of this plasmid was derived from a plasmid made bysAJM.1506 was from Addgene plasmid #108254
-
Article Citing this Plasmid
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
How to cite this plasmid
( Back to top)
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pBLxVi5 was a gift from Christopher Reisch (Addgene plasmid # 167516 ; http://n2t.net/addgene:167516 ; RRID:Addgene_167516) -
For your References section:
A plasmid toolbox for controlled gene expression across the Proteobacteria. Schuster LA, Reisch CR. Nucleic Acids Res. 2021 Jun 14. pii: 6298615. doi: 10.1093/nar/gkab496. 10.1093/nar/gkab496 PubMed 34125913
