pSB4A3-PBAD-phzSM
(Plasmid #165620)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 165620 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pSB4A3
  • Backbone manufacturer
    iGEM
  • Backbone size w/o insert (bp) 3339
  • Vector type
    Bacterial Expression, Synthetic Biology

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    Low Copy

Gene/Insert

  • Gene/Insert name
    phzSM
  • Species
    Pseudomonas aeruginosa
  • Entrez Gene
    phzS (a.k.a. PA4217)
  • Entrez Gene
    phzM (a.k.a. PA4209)
  • Promoter PBAD

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site XbaI (destroyed during cloning)
  • 3′ cloning site SpeI (destroyed during cloning)
  • 5′ sequencing primer CGTCACACTTTGCTATGCCA
    • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pSB4A3-PBAD-phzSM was a gift from Martin Buck (Addgene plasmid # 165620 ; http://n2t.net/addgene:165620 ; RRID:Addgene_165620)
