pGG422_UV5
(Plasmid #165607)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 165607 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pGG422
  • Backbone manufacturer
    Marcus Noyes Lab
  • Vector type
    Bacterial Expression, CRISPR, Synthetic Biology

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    XL1 Blue
  • Growth instructions
    Low or intermediate copy number is expected (high copy is suppressed by the intact rop gene on this plasmid).
  • Copy number
    Unknown

Gene/Insert

  • Gene/Insert name
    lacUV5 driving Streptococcus pyogenes Cas9 KG(D1332K/R1333G) and hEGFP-sgRNA
  • Mutation
    D1332K and R1333G mutations in SpCas9
  • Promoter lacUV5 driving Cas9 KG and UV5 driving sgRNA

Cloning Information

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pGG422_UV5 was a gift from Marcus Noyes (Addgene plasmid # 165607 ; http://n2t.net/addgene:165607 ; RRID:Addgene_165607)

  • For your References section:

    Engineered dual selection for directed evolution of SpCas9 PAM specificity. Goldberg GW, Spencer JM, Giganti DO, Camellato BR, Agmon N, Ichikawa DM, Boeke JD, Noyes MB. Nat Commun. 2021 Jan 13;12(1):349. doi: 10.1038/s41467-020-20650-x. 10.1038/s41467-020-20650-x PubMed 33441553
