Addgene

pGG438
(Plasmid #165486)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 165486 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    MSP469
  • Backbone manufacturer
    Joung Lab (Addgene Plasmid #65771)
  • Vector type
    Mammalian Expression, CRISPR

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    XL1 Blue
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    Mammalian codon-optimized Streptococcus pyogenes Cas9 VRKG(D1135V/S1136R/D1332K/R1333G)-1xNLS(SV40)-3xFlag
  • Mutation
    D1135V, S1136R, D1332K, and R1333G mutations in SpCas9
  • Promoter CMV and T7
  • Tags / Fusion Proteins
    • SV40 NLS (C terminal on insert)
    • 3x FLAG (C terminal on insert)

Cloning Information

  • Cloning method Gibson Cloning
  • 5′ sequencing primer n/a (multiple primers used)
  • 3′ sequencing primer n/a (multiple primers used)
    • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pGG438 was a gift from Marcus Noyes (Addgene plasmid # 165486 ; http://n2t.net/addgene:165486 ; RRID:Addgene_165486)

  • For your References section:

    Engineered dual selection for directed evolution of SpCas9 PAM specificity. Goldberg GW, Spencer JM, Giganti DO, Camellato BR, Agmon N, Ichikawa DM, Boeke JD, Noyes MB. Nat Commun. 2021 Jan 13;12(1):349. doi: 10.1038/s41467-020-20650-x. 10.1038/s41467-020-20650-x PubMed 33441553
