Addgene

pBzCas13b
(Plasmid #164862)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 164862 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pBAD33
  • Backbone size w/o insert (bp) 4010
  • Total vector size (bp) 7716
  • Modifications to backbone
    Arabinose cassette exchanged with insert
  • Vector type
    Bacterial Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Chloramphenicol, 25 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    Bergeyella zoohelcum Cas13b
  • Alt name
    BzCas13b
  • Species
    Bergeyella zoohelcum
  • Insert Size (bp)
    3706
  • Promoter T7 Promoter

Cloning Information

Resource Information

  • Supplemental Documents
  • A portion of this plasmid was derived from a plasmid made by
    Addgene plasmid #89898.

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pBzCas13b was a gift from Chase Beisel (Addgene plasmid # 164862 ; http://n2t.net/addgene:164862 ; RRID:Addgene_164862)

  • For your References section:

    Rapidly Characterizing CRISPR-Cas13 Nucleases Using Cell-Free Transcription-Translation Systems. Wandera KG, Beisel CL. Methods Mol Biol. 2022;2404:135-153. doi: 10.1007/978-1-0716-1851-6_7. 10.1007/978-1-0716-1851-6_7 PubMed 34694607
