pTY1-LacI
(Plasmid #164831)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 164831 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pAN1818
  • Vector type
    Synthetic Biology

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    MG1655dLac
  • Copy number
    Low Copy

Gene/Insert

  • Gene/Insert name
    LacI
  • Alt name
    lac repressor
  • Species
    E. coli
  • Insert Size (bp)
    1083
  • Promoter Ptac

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site AscI (not destroyed)
  • 3′ cloning site XhoI (not destroyed)
  • 5′ sequencing primer CAATTAATCATCGGCTCGTATAATGTGTGGAATT
  • 3′ sequencing primer TGCAGCGAGTCAGTGAGCGAGGAAGCACCTC
    • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pTY1-LacI was a gift from Drew Tack (Addgene plasmid # 164831 ; http://n2t.net/addgene:164831 ; RRID:Addgene_164831)

  • For your References section:

    The genotype-phenotype landscape of an allosteric protein. Tack DS, Tonner PD, Pressman A, Olson ND, Levy SF, Romantseva EF, Alperovich N, Vasilyeva O, Ross D. Mol Syst Biol. 2021 Mar;17(3):e10179. doi: 10.15252/msb.202010179. 10.15252/msb.202010179 PubMed 33784029
