Mito-mGreenLantern
(Plasmid #164461)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 164461 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pcDNA3.1
  • Backbone size w/o insert (bp) -2
  • Vector type
    Mammalian Expression
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    mGreenLantern
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    720
  • Mutation
    Clover-F64L/S72A/E124V/N149K/I167T/S175G/A206K/L221K/F223R/G232D
  • Promoter CMV
  • Tag / Fusion Protein
    • Human COX8a first 29 amino acids (N terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site NcoI (not destroyed)
  • 3′ cloning site XbaI (not destroyed)
  • 5′ sequencing primer CMV-F
  • 3′ sequencing primer BGH-R
    • (Common Sequencing Primers)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    Mito-mGreenLantern was a gift from Gregory Petsko (Addgene plasmid # 164461 ; http://n2t.net/addgene:164461 ; RRID:Addgene_164461)

  • For your References section:

    mGreenLantern: a bright monomeric fluorescent protein with rapid expression and cell filling properties for neuronal imaging. Campbell BC, Nabel EM, Murdock MH, Lao-Peregrin C, Tsoulfas P, Blackmore MG, Lee FS, Liston C, Morishita H, Petsko GA. Proc Natl Acad Sci U S A. 2020 Dec 1;117(48):30710-30721. doi: 10.1073/pnas.2000942117. Epub 2020 Nov 18. 10.1073/pnas.2000942117 PubMed 33208539
